JLG E313 FEATURES AND SPECS
JLG E313 Features
The JLG E313 electric telehandler combines zero-emissions performance with compact maneuverability for indoor and urban worksites. A 48V lithium-ion battery system powers travel and hydraulic functions, offering quiet operation, reduced maintenance and impressive torque. Features like 2WD/4WD switching, rear pivot steering and a universal skid steer coupler give operators the flexibility to tackle a wide range of material handling tasks with confidence.
JLG E313 Benefits
With a lift capacity of 3,500 pounds and a maximum lift height of over 13 feet, the E313 delivers strong performance in a highly compact footprint. The standard 4-in-1 carriage and intuitive single joystick controls make operation fast and precise, while onboard charging and integrated electronic displays help streamline fleet management. For contractors seeking a sustainable telehandler solution without sacrificing capability, the E313 delivers.
JLG 313 Specs
| Drawbar Pull | 3,966 lb (1,764 kg) |
| Lift Capacity at Full Height | 1,800 lb (815 kg) |
| Lift Capacity at Max Reach | 1,415 lb (640 kg) |
| Maximum Lift Capacity | 3,500 lb (1,600 kg) |
| Maximum Lift Height | 13 ft 1 in. (4 m) |
| Maximum Reach | 7 ft 7 in. (2.31 m) |
| Outside Turning Radius | 11 ft 2 in. (3.14 m) |
| Speed - Maximum Lift | 11 sec. |
| Speed - Maximum Lower | 8 sec. |
| Speed - Maximum Telescope In | 4.6 sec. |
| Speed - Maximum Telescope Out | 7 sec. |
| Speed - Maximum Travel | 9.3 mph (15 km/h) |
| Ground Clearance | 10.9 in. (0.27 m) |
| Machine Height | 6 ft 8 in. (2.03 m) |
| Machine Length | 10 ft 1 in. (3.08 m) |
| Machine Width | 4 ft 10 in. (1.48 m) |
| Tire Size | 10.0/75-15.3 Pneumatic Ag Tread |
| Wheelbase | 5 ft 9 in. (1.75 m) |
| Battery | 48V Lithium-Ion - 6 x 3.1 kWh w/ integrated battery heaters, 18.6 kWh capacity |
| Drive | Electric Drive Motor (8.6 kW), Electric Implement Motor (15kW) |
| Maximum Torque | 99 lb-ft (134 Nm) |
| Front Axle | Planetary w/ high bias limited slip diff |
| Rear Axle | Planetary |
| Service Brake Type | Inboard Wet Disc |
| Transmission | Electric 2 Speed |
STANDARD EQUIPMENT, OPTIONS & ATTACHMENTS FOR THE JLG E313
- Adjustable Suspension Seat
- Certified ROPS/FOPS structure
- Horn
- Integrated Arm Rest
- Single Joystick Proportional Controls
- Rear View Mirrors
- 2WD & 4WD Modes
- 4-in-1 Carriage with 48-in Forks
- Aux Hydraulics
- Back-up Alarm
- Hourmeter
- Integrated Electronic Display
- On-Board Smart Charger
- Longitudinal Stability Indicator (LSI)
- Rear Pivot Steering
- Seatbelt Engagement & Operator Assurance
- Tow Hitch
- Universal Skid Steer Coupler (Mechanical)
- Boom Prop
- Enclosed Cab
- Front Brick Guard
- High Aux Flow (10.5 gpm / 39.5 lpm)
- Hydraulic Universal Skid Steer Coupler
- Road Lights
- Wiper Package
- Work Lights
- Pallet Forks: 1.4 in x 3.9 in x 40 in (35 mm x 100 mm x 1.0 m)
- General Purpose Bucket: 63 in. (1.6 m)
Interested in buying the JLG E313? Contact MJ Equipment today!
