Construction Equipment Supplier

SkyTrak Telehandler 3013



JLG & Skytrak FinancingSkytrak JLG equipment sale

Key Specs

  • Maximum Lift Capacity: 2700 lb / 1224.70 kg
  • Maximum Lift Height: 13 ft 1 in. / 3.99 m
  • Maximum Reach: 7 ft 1 in. / 2.16 m

See all specs

Key Features

  • Work in Confined Environments: Ultra-compact and highly maneuverable design
  • Enhance Your Capabilities: Excellent reach into truck beds, trailers, and over obstacles
  • Keep Your Surroundings Intact: Rear-wheel steering for less ground disturbance

Performance

Drawbar Pull 2632 lb / 1189.77 kg
Lift Capacity at Full Height 1555 lb / 705.34 kg
Lift Capacity at Max Reach 1200 lb / 544.31 kg
Maximum Lift Capacity 2700 lb /1224.70 kg
Maximum Lift Height 13 ft 1 in. / 3.99 m
Maximum Reach 7 ft 1 in.  / 2.16 m
Outriggers or Stabilizers No
Outside Turning Radius 9 ft 9 in. / 2.97 m
Speed - Maximum Lift 10.9 sec.
Speed - Maximum Lower 7.7 sec.
Speed - Maximum Telescope In 4.5 sec.
Speed - Maximum Telescope Out 7.5 sec.
Speed - Maximum Travel 10.5 mph / 16.90 km/h

Standard Specifications

Ground Clearance 10 in. / 0.25 m
Machine Height 6 ft 7 in. / 2.01 m
Machine Length 8 ft 9 in. / 2.67 m
Machine Width 4 ft 7 in. / 1.4 m
Tire Size 11 / 65 x 12 Pneumatic Ag Tread
Wheelbase 5 ft 7 in. / 1.7 m

Power Source

Capacity - Fuel Tank 14.5gal. / 54.89 L
Engine Horsepower 24.8 hp / 18.50 kW
Engine Manufacturer Kubota
Engine Model V-1505
Maximum Engine RPM 2300 rpm

General

Axle-Front High Bias, Limited Slip
Axle-Rear Oscillating
Function Pump Type Gear
Operating Vehicle Weight 5280 lb / 2394.97 kg
Transmission Type Hydrostatic
Contact our sales department online or at 1-877-355-5438 for current pricing and availability on new JLG telehandlers.
